QModule Class Reference

Inheritance diagram for QModule:

List of all members.

---

Detailed Description

Pure abstract class that every Diana module should inherit from.

• Config example:

     module ModuleName
    # mandatory parameters
     verbosity = info
     enable = true
    # module specific parameters
     myvarint = 1
     myvardouble = 1.0
     myvarstring = hellocuore!
     myvarbool = true
     endmod


• Parameters:
  • verbosity: only messages above the verbosity level are displaied:
    • debug
    • info
    • warn
    • error
    • panic
  • enable:
    • true: module will be executed inside the sequence
    • false: module will not be executed

Public Member Functions
	QModule (const std::string &, QSequence *s)
Protected Member Functions
const QError &	JumpToEvent (unsigned int event)
	next iteration diana will jump to event
virtual void	Init ()=0
	Init method is called before event loop.
virtual QEvent *	Do (QEvent *ev)=0
	Doit method is called for each event, getting the event as argument.
virtual void	Done ()=0
	Done method is called after event loop.
Private Member Functions
void	Begin ()
	Begin method is called before event loop.
QEvent *	Process (QEvent *ev)
	Process method is called for each event, getting the event as argument.
void	End ()
	End method is called after event loop.

---

The documentation for this class was generated from the following files:

• /usr/local/cuore/pkg/dianaframework/QModule.hh
• /usr/local/cuore/pkg/dianaframework/QModule.cc

---
